SystemAPI
舒尔设备的控制和监控
应用程序编程接口，用于控制和监测Shure设备的各种产品功能和性能参数，现场或远程操作皆可。SystemAPI采用开放式体系结构，可与第三方设备和平台集成，以实现全面且可自定义的系统管理。
兼容产品
MXA920
天花麦克风阵列
Automatic Coverage™技术可以无需额外设置，即可以精确控制音频捕获。 MXA920具有用于增强定向拾音和更自然语音的新一代阵列架构，易于使用且可快速部署用于AV会议、摄像头跟踪、语音提升或扩声。
MXA710
线性麦克风阵列
MXA710无论是在壁挂式显示器的下方还是旁边，从天花板悬挂下来还是齐平地安装在桌子上，都可以巧妙地融合到任何设计风格的会议室中，而不会牺牲优质的音频质量，这一切都能通过全新的Microflex Advance产品中实现。
MXA310
桌面麦克风阵列
MXA310 采用Steerable Coverage™，包含4个独立拾音模式和全新环形拾音模式，可抑制上方的空调声和风扇噪音。直观的用户界面，可以轻松配置预设值、模板和拾音模式。
MXA902
天花麦克风阵列 — — 拾扩音一体机
将麦克风、扬声器和DSP集成，适合中小型空间内的AV会议。单分区Automatic Coverage™技术在20 x 20英尺的区域内捕捉发言者声音。
支持
客户支持
技术资源
文档
快速入门指南
-
insert_drive_file
概要
-
insert_drive_file
-
insert_drive_file
发行说明
Version 6.0.0
Initial Release
Known Issues
- Subscriptions to AudioChannelGainEvent will return duplicative responses for MXA901, MXA902, and MXA920 devices.
- Subscribing to battery-level may return CALCULATING for status, timetoTargetState, targetState properties on MXW classic devices. To work around, use the GET battery-level capability.
- Subscriptions to FirmwareUpdateProgressEvent on MXA310 will skip TRANSFERRING_FILES and INSTALLING stages. Only PENDING and COMPLETE will be returned.
- Subscriptions to UserPresetEvent will return duplicative responses upon a save event.
Platform Requirements
- Supported Operating Systems
- Windows 10, 11 or Windows Server 2016, 2019, 2022
- Hardware Requirements
- Minimum:
- Dual Core 64-bit Intel or AMD processor
- 2GB RAM
- Recommended:
- 64-bit Intel or AMD processor
- 8GB RAM
- Minimum:
Notes
Compatibility
- Whenever possible, upgrade to the latest supported firmware version to take advantage of new features and system improvements.
- All previously released firmware versions support Device Discovery and Firmware Update
- To operate this version of System API with feature interactivity, see the following list of Shure devices and firmware versions:
| PRODUCT | MINIMUM SUPPORTED VERSION FOR FEATURE INTERACTIVITY |
| P300 | 6.0.38 |
| ANISUB | 6.0.44 |
| MXA310, MXA710, MXA910, MXA920, MXA901, MXA902 | 6.0.X |
| MXN5-C | 6.0.17 |
| MXA MUTE | 6.0.25 |
| MXWANI4, MXWANI8 | 10.0.6 |
| MXWAPT2, MXWAPT4, MXWAPT8 | 10.0.8 |
| MXW1/2/6/8 | 10.0.6 |
| MXWNCS2/4/8 | 10.0.6 |
| QLXD4 | 2.5.2 |
| ULXD4/D/Q | 2.7.X |
| ULXD6/8 ** | 2.7.X |
| SBC250/450/850 | 2.7.X |
| SBC220/240 | 1.3.45 |
| MXWAPDX2 | All released firmware |
| MXW1X/2X/6X | All released firmware |
**Only supports connectivity with SystemAPI when docked in SBC250/450/850 charger(s).
